WIRED TRACKER

BrayTelematics Wired Live GPS Tracker delivers real-time vehicle tracking with rock-solid connectivity — even in the most challenging conditions.

$10.00 / month and a $65.00 sign-up fee

Buy Now
Add to Cart

GSM Specification

GSM RF chip

GSM channel

GPRS class

Communication Protocol

Body Memory

Phase Error

Maximum Output

Maximum Frequency Error

SIMCOMEA7670E

FDD:B1/B2/B3/B4/B5/B7/B8/B28/B66 GSM:850/900/1800/1900 MHz

LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28/B66 GSM 850/900/1800/1900 MHz

Class 12,TCP/IP

TCP/IP

8MB

-5°~5°

32+3dBm

±0.1ppm

GPS Specifications

GPS chipset

Positioning Mode

Number of channels

Positioning accuracy

Tracking sensitivity

Capture sensitivity

Positioning time

AT6558R

BDS/GPS/GNSS/LBS

72

<10m

-163dBm

-148dBm

Avg.hot start <2s Avg.warm Start <28s Avg.cold start <38s

Working Parameters

Device Agreement

Operating Voltage Range

Working Current

Quiescent Current

Battery

Continuous Working Time

Continuous Stationary Battery Life

Storage Capacity Of Blind Spot Track Points

Operating Temperature

Working Humidity

Dimensions

Weight

Waterproof And Dustproof Grade

GT06

9-90V/45mA(12V)

50MA/12V

12mA

100mAh

2~3h

5h

500

-20°C~70°C

-40°C~+85°C

L80mm*W32mm*H15mm

36g

IP65
